Ask five vendors what drafting costs and you get five different numbers, because they are quoting five different things. An hourly freelance rate, a firm’s blended rate, a per-sheet redline price and a monthly dedicated-team retainer are not the same unit, and comparing them directly is how a number gets misquoted.
The short answer: published 2026 rates put CAD drafting at roughly $18 to $85 an hour, per-sheet work at $25 to $180 depending on turnaround, and dedicated-team retainers from about $2,000 to $8,000 a month. Every range depends on scope and who is quoting, so treat this as a check, not a price to expect.
This page is for principals and ops managers who want to sanity-check a quote. It compiles rates published by pricing pages, market data providers and vendors, each dated and sourced, organized by task and unit. Skyline has not published its own rates; where this page mentions Skyline, it says so.
Why rates vary so much
Four things move the number before anyone talks about skill or quality.
- The unit. Hourly, per sheet, per square foot, monthly retainer, or flat per project. A “$25” number is meaningless without its unit.
- Who is billing. A freelancer, a small firm, a large outsourcing vendor and an in-house architect all carry different overhead.
- Turnaround. Cad Crowd’s own published redline pricing nearly triples for a one-day rush versus standard service. Speed costs.
- Region. Coastal, high-cost metros run higher than the rest of the country in every source below that breaks out geography.
Keep these four in mind reading the table. They explain most of the spread.
Hourly and salary rates
| Rate | Source | As published |
|---|---|---|
| $17.81 to $32.38/hr, median $23.93/hr | PayScale, CAD Drafter | 1,125 salary profiles, last updated July 14, 2026 |
| $32.74/hr median ($68,090/yr); $66,150/yr for architectural and civil drafters | U.S. Bureau of Labor Statistics, Occupational Outlook Handbook | May 2025 data, page modified August 27, 2026 |
| $75 to $150/hr | Angi, draftsperson cost guide | Updated September 16, 2026 |
| $30 to $120/hr; freelance $30–$85, firm/company $80–$120 | HomeGuide, blueprints and house plans cost | Page dated September 20, 2023 |
| $75 to $125/hr for a draftsman; $350 to $400/hr for an architect | Cad Crowd blog, drafting services rates | Published August 2021, updated March 2023 |
| $30 to $80/hr for experienced outsourced drafters | CADTRI, outsource CAD drafting cost analysis | July 10, 2026 |
| Entry freelance $30–$50/hr; experienced freelance $50–$80/hr; firms $60–$80/hr; regional high (NYC, SF, LA) often over $80/hr, moderate metros $50–$70/hr | Civil Outsourcing, drafting services cost | Published November 2024, modified December 2025 |
| From about $18/hr | Zedtreeo, architectural drafting services | Read September 2026, undated |
| About $75/hr basic, about $125/hr with PM and design | Brandywine CAD, outsource drafting services | Modified July 14, 2026 |
| $20/hr for CAD, $25/hr for Revit/BIM | ArchiCGI, drafting service pricing | Read September 2026, undated |
Per-sheet and per-project rates
| Rate | Source | As published |
|---|---|---|
| $35 to $180 per sheet (AutoCAD drafting, by turnaround) | HomeGuide | September 20, 2023 |
| Redline markups about $55/sheet standard, nearly $155/sheet for one-day rush | Cad Crowd blog | August 2021, updated March 2023 |
| Redline $55/sheet standard, $155/sheet rush; overnight, 3-day and 5-day table | Cad Crowd (rates page) | Updated November 4, 2024 |
| From $25/sheet | Zedtreeo | Read September 2026, undated |
| $0.25 to $0.75 per square foot (outsourced) | CADTRI | July 10, 2026 |
| $0.35 to $5.00 per square foot; full house plan set $700 to $10,000 | HomeGuide | September 20, 2023 |
| National average $1,731 per project; typical range $815 to $2,710; permit drawings $1,000 to $3,000; as-built plans $700 to $2,000 | Angi | September 16, 2026 |
| Site plan $300 to $1,000; structural drawing $500 to $2,000 | My Site Plan, architectural drawing plan costs | March 31, 2025 |
Retainers, staffing and dedicated teams
| Rate | Source | As published |
|---|---|---|
| Monthly retainer $3,000 to $8,000 | CADTRI | July 10, 2026 |
| From about $2,000/month for a dedicated team; $7/hr for staffing-only arrangements | Zedtreeo | Read September 2026, undated |
| First-year in-house cost $65,000 to $90,000; ongoing annual $55,000 to $75,000 (salary, benefits, software, hardware, office) | CADTRI | July 10, 2026 |
How to read a quote against this index
Three questions, in order.
- What unit is the quote in? Match it to the right table above before comparing numbers.
- What is the turnaround? A rush rate is not comparable to a standard one. Cad Crowd’s own figures show close to a 3x difference.
- What is included? A per-sheet rate may or may not include revisions, coordination or QA. Ask, and put the answer in the scope note (see the cost model guide).
A quote that lands outside these ranges is not automatically wrong. It may reflect scope, complexity or region this index does not capture. But it is a reason to ask what is different.
What this index does not tell you
It does not price Skyline. Skyline has not published rates on its site, and none of the figures above come from Skyline. If you want Skyline’s pricing, ask directly.
It is not search volume, and it is not a quality signal. A $20-an-hour rate and an $80-an-hour rate can both be a fair price for different scopes. Cheaper is not automatically worse, and expensive is not automatically better. Check the scope, not just the number.
It goes stale. Every rate above carries the date it was published or last modified. Some are current for 2026; a couple date to 2023 and 2021 and are included because they are still live, cited pages, not because they are fresh. Check the date before you rely on a number.
Get a quote you can actually compare
If you want a number specific to your project instead of a market range, you can request a scope review: send one drawing set, your standards and a note on what you would keep in your own office. You will get a quote for that scope, in writing, that you can check against the ranges above.
Sources
- CAD Drafter Hourly Rate, PayScale (last updated July 14, 2026)
- Occupational Outlook Handbook: Drafters, U.S. Bureau of Labor Statistics (May 2025 data, page modified August 27, 2026)
- Draftsperson Cost Guide, Angi (updated September 16, 2026)
- 2026 Cost of Drafting House Plans, HomeGuide (page dated September 20, 2023)
- Drafting Services Rates, Costs and Differences in Pricing, Cad Crowd (published August 2021, updated March 2023)
- Should Your Firm Outsource CAD Drafting? Cost Analysis, Shahzaib Nadeem, CADTRI (July 10, 2026)
- Drafting Services Cost, Civil Outsourcing (published November 27, 2024, modified December 4, 2025)
- Architect to Draw Plans: The 2026 Cost Guide, My Site Plan (published December 12, 2024, modified March 31, 2025)
